indoor outdoor curtain LED display screen

indoor outdoor curtain LED display screen


Lightweight,Super thin,Transparent,Suitable for use both indoors and outdoors,High refresh rate,Easy to set up and tear down.

1.With a design that features excellent lightweight, super thinness and transparency, the panel do provide a total solution that can meet the demands of rental business, including concerts, movies, TV sets and events.

2.This design can save your time in setting up and tearing down, also labor costs and transportation costs. High quality SMDs technology, and unique hardware can provide fantastic video performance.

3.Fully waterproof at the front and rear, these panels are very suitable for both outdoor and indoor use.

4.  Deep, uniform  colors and new level of grayscale range.

Pixel pitch 16 mm
Brightness 2000nits
Refresh Rate 800Hz
Pixel configuration SMD 3 in 1
Hor. viewing angle 140° (min 50% brightness)
Vert. viewing angle 140° (min 50% brightness)
Lifetime 100,000 hours to 50% of initial brightness
Power consumption 400W/panel (max)
Panel dimensions 768mm x 768mm x 60mm
Panel Material Aluminum
Weight / Panel 9 kg
IP rating IP 43
Processing 16 bit/color
Colors 281 Trillion
Recommended Min Viewing distence 16m
Grey scale (linear) 65,536 levels per color
Link interface DVI
Operating temperature -20 - 45°C
Storage temperature -20 - 50°C
Operational humidity 10-99%
Storage humidity 10-99
