LED display Wireless 3G Communication Solution

LED display Wireless 3G Communication Solution

Communication theory introduction: LED control card will auto connect to the Led Editor service center running in remote PC-console through domain name parameter so as to building up a communication link



WIFI solution
Preparations:
Hardware: Wireless access point (WAP), xixun led controller, network
cable
Software: xixun software

Connection diagram:

 Take TL-WA801N(WAP for short) and an M card for example:
When you have a WAP in hand, you will see following information on the
back side:
IP address: 192.168.1.25
User: admin
Password: admin

1. Setup WAP
Connect this WAP with PC via network cable directly. I am following
the guidance book:
Set PC’s Local IP address: 192.168.1.100
Subnet mask: 255.255.255.0

2. Open Internet Explore and write down IP of WAP: 192.168.1.254
Write down user name and password

3. Now you are in setup interface, just following the guidance,
Start- wireless working mode
Choose Client and Next

4. Now setup for Client mode:
There is a Scan option, press it and then it will search WIRELESS
HOPSPOT nearby, you choose one and then it asked for Password. If this
hotspot has a password then enter, if no then no need to write down,
leave it alone.

 Here are the lists of hotspots near my office, I choose one and then press
connection.


Then it will auto recognize the SSID (FAST_FCF642) and MAC
(00-25-86-FC-F6-42).
Now press next and enter DHCP part, no need to do anything here, just
go on for next step

Now it saying setup finished, WAP will restart, OK. Press Restart button.

 5. Setup controller.
Connecting led controller with PC via network cable directly; detect
controller IP address and then Enter Hardware setup.

Here are three parts need to set.
One is IP address
 Subnet mask
 Default
Make sure that IP address and default should be in the same network
segment.

Server information, no need to change anything if use our server, just
press Send.

Data center: write down your own user name and press Send.

6. Finished controller setup now.

7. Then you move the PC away, connecting WAP with led controller via
network cable directly and so as to get accessing to internet.

8. Then PC in office or at home getting internet could send program to
led controller.
