|LED display basic concepts and led rental display advertising|
1 What is LED? LED is the abbreviation of Light Emitting Diode (Light emitting diode). The "LED" in the display industry refers to LEDs that emit visible light.
2 What is a pixel? The minimum illuminating pixel of the LED display wall has the same meaning as the "pixel" in the ordinary computer display;
3 What is the pixel distance (point spacing)? The distance from the center of one pixel to the center of another pixel;
4 What is the LED display unit module? A small unit consisting of several display pixels that are structurally independent and can form an LED display. Typical "8*8", "8*16", "16*16", etc., can be assembled into modules by specific circuits and structures;
5 What is DIP? DIP is the abbreviation of Double In-line Package, dual in-line assembly;
6 What is SMT? What is SMD? SMT is the surface mount technology (short for Surface Mounted Technology), which is currently the most popular technology and process in the electronics assembly industry; SMD is a surface mount device (short for Surface mounted device);
7 What is the LED display module? A basic unit defined by a circuit and an installation structure, having a display function and capable of realizing a display function by simple assembly;
8 What is an LED display? a display screen composed of an array of LED devices by a certain control method;
9 What is a plug-in module? What are the advantages and disadvantages? It means that the lamp of DIP package passes the lamp foot through the PCB board, and the tin is filled in the lamp hole by soldering. The module made by this process is the plug-in module; the advantage is that the viewing angle is large, the brightness is high, and the heat dissipation is good. The disadvantage is that the pixel density is small;
10 What is a surface mount module? What are the advantages and disadvantages? The surface mount is also called SMT. The SMT packaged lamp is soldered to the surface of the PCB board through the soldering process. The lamp pins do not need to pass through the PCB board. The module made by this process is called the surface mount module. The advantage is: the display effect is good. The pixel density is large, suitable for indoor viewing; the disadvantage is that the brightness is not high enough, and the heat dissipation of the lamp itself is not good enough;
11 What is the sub-surface module? What are the advantages and disadvantages? A sub-surface sticker is a product between DIP and SMT. Its LED lamp has the same package surface as SMT, but its positive and negative pins are the same as DIP, and it is also soldered through the PCB during production. The advantages are: high brightness, good display effect, disadvantages: complicated process and difficult maintenance;
12 What is 3 in 1? What are its advantages and disadvantages? It refers to packaging three different color LED chips of R, G and B in the same glue body; the advantages are: simple production, good display effect, disadvantages: light separation and color separation, high cost; PLCC-4 SMD (3528, TOP) Plastic has a lead chip carrier PLCC (Plastic Leaded Chip Carrier),
13 What is 3 and 1? What are its advantages and disadvantages? The difference between CHIP SMD and PLCC SMD (3 in 1, 3 and 1) 3 and 1 means that R, G, B three independently packaged SMT lamps are vertically juxtaposed at a certain pitch, so that not only has 3 in 1 all. The various advantages can also solve the various shortcomings of 3-in-1;
14 What is the double primary color, pseudo color, full color display? Different color LEDs can be used to form different display screens. The two primary colors are composed of red, green or yellow and green. The pseudo color is composed of three different colors: red, yellow green and blue. The full color is red. , pure green, pure blue composed of three different colors;
15 What is the brightness of the light? The intensity of light emitted by the unit area of the LED display, in cd/m2, is simply the intensity of light emitted by a display of one square meter;
16 What is the brightness level? The number of levels of manual or automatic adjustment of the entire screen brightness from the lowest to the highest brightness;
17 What is gray level? The number of technical processing stages between the darkest and the brightest at the same brightness level;
18 What is the maximum brightness? Under certain ambient illumination, the primary color of the LED display advertising is at the maximum brightness and maximum gray level;
19 What is a PCB? PCB is a printed circuit board (short for Printed Circuit Board);
20 What is a BOM? BOM is a bill of materials (abbreviation of Bill of material);
21 What is white balance? What is white balance adjustment? The white balance we refer to refers to the balance of white, that is, the balance of the brightness ratios of the three colors of R, G, and B; the ratio of the brightness of the three colors of R, G, and B and the adjustment of the white coordinates, called white balance adjustment. ;
22: What is contrast? The ratio of the maximum brightness of the LED display to the background brightness under a certain ambient illumination;
23: What is the color temperature? When the color of the light emitted by the light source is the same as the color of the black body at a certain temperature, the temperature of the black body is called the color temperature of the light source.
24: What is the frame change frequency? The number of times the display screen information is updated in a unit time;
25: What is the refresh rate? The number of times the display screen is repeatedly displayed by the display;
26: What is the perspective? What is the angle of view? What is the best perspective?
The viewing angle is the angle between the two viewing directions of the same plane and the normal direction when the brightness of the viewing direction drops to 1/2 of the brightness of the normal direction of the LED display screen. Divided into horizontal and vertical perspectives;
The angle of view is just the direction in which the image content on the display screen can be seen, and the angle formed by the normal of the display screen;
The best viewing angle is the ability to see the content on the display just in full, and without color cast, the sharpest direction of the image content and the normal angle;
27: What is the best line of sight? Is able to just see the content on the display completely, and does not color cast, the sharpest position of the image content relative to the vertical distance of the screen;
28: What is the point of loss? How many? Pixels whose illuminating state does not match the control requirements; the out-of-control points are divided into: blind spot (also known as dead point), constant bright point (or dark point), and flash point;
29: What is a static driver? What is a scan driver? What is the difference between the two?
The "point-to-point" control from the output pin of the driver IC to the pixel is called static drive; the "point-to-column" control from the output pin of the driver IC to the pixel is called scan drive, which requires a row control circuit; It can be clearly seen from the driver board: the static drive does not require a row control circuit, and the cost is high, but the display effect is good, the stability is good, the brightness loss is small, etc.; the scan drive requires a row control circuit, but the cost is low. Poor display effect, poor stability, large loss of brightness, etc.;
30: What is constant current drive? What is a constant voltage drive? Constant current refers to the current value specified in the constant output design within the working environment allowed by the driver IC; constant voltage refers to the voltage value specified in the constant output design within the working environment allowed by the driver IC;
31: What is nonlinear correction? If the digital signal output by the computer is not corrected, the color distortion will appear on the LED display. Therefore, in the system control circuit, the signal output by the original computer is subjected to a non-linear function to calculate the signal required by the display screen. Since the front and back signals are nonlinear, we often call it a nonlinear correction;
32: What is the rated working voltage? What is the working voltage? What is the supply voltage? The rated working voltage refers to the voltage when the appliance is working normally; the working voltage refers to the voltage value of the appliance under the rated voltage range and normal operation; the supply voltage is divided into AC and DC supply voltage, and our display AC supply voltage is AC220V~240V, DC power supply voltage is 5V;
33: What is color distortion? Refers to the same object in nature and on the display, the difference between the two for the human eye's sensory vision;
34: What is a synchronous system and what is an asynchronous system?
Synchronous and asynchronous are relative to the computer. The so-called synchronous system refers to the LED display control system that displays the content displayed on the display and the computer display. The asynchronous system means that the computer-edited display data is stored in advance. In the display control system, after the computer is turned off, it will not affect the normal display of the LED display. Such a control system is an asynchronous system;
35: What is the blind spot detection technology? Through the host computer software and the underlying hardware, the blind spot (LED open and short circuit) on the display can be detected, and a report is generated to tell the LED screen manager that such a technique is called blind spot detection. technology;
36: What is power detection? Through the upper computer software and the underlying hardware, the working status of each power supply on the display can be detected, and a report is generated to tell the LED screen manager that such a technology is called power detection technology;
37: What is brightness detection? What is brightness adjustment? The brightness in brightness detection refers to the ambient brightness of the LED display. Through the light sensor, the ambient brightness of the display is detected. This detection method is called brightness detection. The brightness mentioned in the brightness adjustment refers to the brightness of the light emitted by the LED display screen. The detected data is fed back to the LED display control system or the control computer, and then the brightness of the display screen is adjusted according to the data, which is called brightness adjustment;
38: What is a real pixel? What is a virtual pixel? How many virtual pixels are there? What is pixel sharing?
The real pixel refers to the relationship between the number of physical pixels on the display screen and the number of actually displayed pixels is 1:1. How many points actually appear on the display screen can only display image information of how many points;
The virtual pixel means that the number of physical pixels on the display screen and the number of actually displayed pixels are 1:N (N=2, 4), and the image pixels that can be displayed are 2 times or 4 times more than the actual pixels of the display screen;
According to the virtual control method, virtual pixels can be divided into: software virtual and hardware virtual; according to the multiple relationship: 2x virtual and 4x virtual, according to the lighting mode on one module: 1R1G1B virtual and 2R1G1B virtual;
39: What is remote control? Under what circumstances? The so-called remote is not necessarily a long distance. The remote control includes the main control terminal and the controlled terminal in a local area network, and the spatial distance is not far; and the main control terminal and the controlled terminal are within a relatively long distance; the customer requests or directly exceeds the optical fiber according to the customer control position. Control the distance, then use remote control;
40: What is fiber transmission? What is network cable transmission? Optical fiber transmission is to convert electrical signals into optical signals by transparent glass fiber transmission; network cable transmission is to use metal wires to directly transmit electrical signals;
41: Under what circumstances use the network cable? When do you use fiber? When the distance between the display screen and the control computer is less than 100M, the network cable is used for transmission; when the distance between the two is less than 500M and greater than 100M, the multimode fiber is used, and when the distance is greater than 500M, the single mode fiber is used;
42: What is LAN control? What is internet control? In the LAN, another computer is connected to an external device connected to it through a computer. This control method is called LAN control; the host controller accesses the IP address of the controller in the Interner network to achieve the purpose of control. Called Internet control;
43: What is DVI? What is VGA? DVI is the abbreviation of Digital Video Interface, which is digital video interface. It is a digital video signal interface that is now internationally accepted;
The full name of VGA in English is Video Graphic Array, which is a display graphics array. It is a video signal interface of three analog outputs of R, G and B;
44: What is a digital signal? What is a digital circuit? The digital signal means that the value of the signal amplitude is discrete, and the amplitude representation is limited to two finite values of 0 and 1. The circuit for processing and controlling such a signal is called a digital circuit;
45: What is an analog signal? What is an analog circuit? The analog signal means that the value of the signal amplitude is continuous over time; the circuit that processes and controls such a signal is called an analog circuit;
46: What is a PCI slot? A PCI slot is an expansion slot based on a PCI local bus (Pedpherd Component Interconnect).
The PCI slot is the main expansion slot of the motherboard. By plugging in different expansion cards, you can get almost all external functions that can be realized by the current computer.
