LED display technical parameters-led video display advertising led module led panels
Indoor screen series
The indoor LED screen area is generally less than ten square meters, the point density is high, and it is used in non-direct sunlight or lighting environment. The viewing distance is several meters away, and the screen body does not have sealing and waterproofing ability. According to the control method and display color, it can be divided into the following types:
● Indoor full color video screen
  ★ Adopt independent point-by-point correction technology to ensure uniformity between points.
  ★ The light-emitting point of the display panel adopts a column-shaped flat-head LED, which has been tested.
  The vertical and horizontal full viewing angles can reach 150 degrees.
  ★ The reflector that forms the lamp panel is made by opening the mold and seamlessly matches the light-emitting point.
  The surface height error is minimal.
  ★ Using LEDs, the brightness of the light is 6-8 times the brightness of the light-emitting chip.
  ★ The heat of the LED is mainly lost from the metal pin, which determines the display panel.
  Has good heat dissipation performance.
  ★ Bad LEDs can be replaced one by one, without affecting the use of other LEDs.
  Reduce maintenance costs.
  ★ Using the latest technology level video control system, the display color is bright and clear.
  ★ Main technical parameters
  Base color RGB (full color) pixel diameter [mm] 5.00 8.00
  Pixel pitch [mm] 7.62 10.00
  Pixel composition 1R1G1B 2R1G1B virtual pixel
  Unit panel points [dot] 32×32 32×16
  Unit panel size [mm] 245×245 320×160
  Unit panel weight [g] 1100 850
  Physical pixel density [point / m2] 17200 10000
  Virtual pixel density [point / m2] 16384 40000
  Peak power consumption [W/m2] 850 750
  Average power consumption [W/m2] 350 320
  Weight [Kg/m2] <36 <36
  Horizontal viewing angle 150°
  Vertical viewing angle 150°
  Highest brightness [cd/m2] 1700 800

● Indoor double color video screen wall
  ★ The display module adopts Dachang products, and the brightness and illumination consistency of the whole screen is good.
  ★ The system is stable and mature, the installation is simple without debugging, and the failure rate is extremely low.
  ★ Using the latest technology level video control system, the display color is bright and clear.
  ★ Main technical parameters
  Primary color RG (red, green double primary color)
  Pixel diameter [mm] 3.75 5.00
  Pixel pitch [mm] 4.75 7.62
  Pixel composition 1R1G 1R1G
  Unit panel points 64×32 (or 80×32) 80×32
  Unit panel size [mm]
  306 × 153 (or 382 × 153)
  612×245
  Unit panel weight [g] 800 1500
  Pixel density [point / m2]
  43000 17200
  Peak power consumption [W/m2] 700 350
  Average power consumption [W/m2] 300 200
  Viewing angle 150°
  Communication distance (m) 100 (no relay)

● Indoor monochrome screen
  ★ The display module adopts Dachang products, and the brightness and illumination consistency of the whole screen is good.
  ★ The system is stable and mature, the installation is simple without debugging, and the failure rate is extremely low.
  ★ Depending on the usage requirements, synchronous or asynchronous methods can be used.
  ★ Main technical parameters
  Primary color
  Pixel diameter [mm] 3.0 3.75 5.00
  Pixel pitch [mm] 4.0 4.75 7.62
  Pixel composition 1R 1R 1R
  Unit panel points [dot]
  64×32 64×32 80×32
  Unit panel size [mm]
  306×153 612×245
  Unit panel weight [g]
  700 900 1500
  Pixel density [point / m2]
  62500 43000 17200
  Peak power consumption [W/m2]
  500 350 200
  Average power consumption [W/m2]
  350 200 100
  Viewing angle 150°
  Communication distance (m) 100 (no relay)

Semi-outdoor screen series
The semi-outdoor screen generally uses a single light to form a light-emitting point, and is suitable for an environment with high brightness and waterproofness, for example, under the eaves, in the window, and in a hall with strong light. The dot pitch is generally around 7.62mm-10mm; the illuminating color is generally single red or red/green double primary color; the control mode is asynchronous, synchronous graphic, video, etc. according to the use requirements.

  ★ Main technical parameters
  Primary color / double primary color
  Pixel diameter [mm] 5.00 5.00
  Pixel pitch [mm] 7.62 10.00
  Pixel composition 1R 1R
  Unit panel points [dot] 80×32 32×16
  Unit panel size [mm] 612×245 320×160
  Unit panel weight [g] 1700 1000
  Pixel density [point / m2] 17200 10000
  Peak power consumption [W/m2] 400 300
  Average power consumption [W/m2] 250 200
  Horizontal viewing angle 60-70°
  Vertical viewing angle 45-60°
  Maximum brightness [cd/m2] 3000 1800

Outdoor screen series
The outdoor screen area is generally more than ten square meters, the brightness is high, and it can be used in a direct sunlight environment. The viewing distance is generally more than ten meters, and the screen body is sealed and waterproof. According to the control method and display color, it can be divided into the following types:

● Outdoor full color video screen
  ★ The light-emitting point of the display panel is light-emitting diode with solid color and high brightness.
  The effect is real and natural.
  ★ The light board is a box structure, which is easy to install and has a flat appearance.
  ★ Using the latest technology level video control system, the display color is bright and clear.
