Indoor Rental LED Display

Outdoor Rental LED Display

Small Pixel HD led video TV, functioning like a high resolution TV.

&. Small pixels: 2.5mm; Cabinet size is 480x480mm.

&. Full HD led video wall with vivid colors,acting like a TV

&. Leading technology of high grey level andlow brightness, contrast ratio 5000:1, processing depth 16bit, refresh rate3200Hz

&. Wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability

&. Seamless, bezel-free, size-free splicing with adjusting accuracy is 0.01mm

&. Metal cooling structure, no noise and no fan

&. Die-casting aluminum design, CNC precise processing

&. Modular front maintenance, supporting hotplugging for unit module and wires

Pixel Pitch	2.5mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD2121
Brightness	800 cd/m²
Color temperature	6500K
Viewing angle	H: 160°; V:160°
Pixel density	160000 pixels/m²
Viewing distance	≥2.5 M
Module size	160mm×160mm
Cabinet size	W480mm×H480mm×D90mm
Weight	8 kg/panel
Area	0.2304 m²
Material	Die-casting Aluminum
Aspect ratio	1:1
Ingress protection	IP30
Operating Temperature	0℃~+45℃/10~90%RH
Storage Temperature	-10℃~+55℃/10~90%RH
Pixels per panel	192×192 Dots
Gray scale	16 bits
Processing depth	65536 levels per color
Color	281.4 trillion
Brightness control	Manual/Automatic
Contrast ratio	5000:01:00
Rate refresh	≥3200 Hz
Input voltage	110~240VAC
Input power frequency	50~60 Hz
Driving Method	1/16 Scan, Constant Current
Rigging form	Hanging/Fixed with support bracket
