P1.9mm Small Pixel HD led video TV, functioning like a high resolution TV.

&. Small pixels: 1.9mm; Cabinet size is 480x480mm.

&. Full HD led video wall with vivid colors,acting like a TV

&. Leading technology of high grey level andlow brightness, contrast ratio 5000:1, processing depth 16bit, refresh rate 3200Hz

&. Wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability

&. Seamless, bezel-free, size-free splicing with adjusting accuracy is 0.01mm

&. Metal cooling structure, no noise and no fan

&. Die-casting aluminum design, CNC precise processing

&. Modular front maintenance, supporting hotplugging for unit module and wires

Pixel Pitch	1.904mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD1010
Brightness	800 cd/m²
Color temperature	6500K
Viewing angle	H: 160°; V:160°
Pixel density	275625 pixels/m²
Best Viewing distance	≥2 M
Module size	240mm×240mm
Cabinet size	W480mm×H480mm×D86mm
Weight	8kg/panel
Material	Die-casting Aluminum
Ingress protection	IP30
Operating Temperature	0℃~+45℃/10~90%RH
Storage Temperature	-10℃~+55℃/10~90%RH
Pixels per panel	252×252 Dots
Gray scale	16 bits
Processing depth	65536 levels per color
Color	281.4 trillion
Brightness control	Manual/Automatic
Contrast ratio	3000:01:00
Video frame rate	50/60 Hz
Rate refresh	≥3200 Hz
Input voltage	110~240VAC
Input power frequency	50~60 Hz
Life Time	≥100,000 Hours
LED Wavelength	R:620~630nm G:520~535nm B:465~475nm
Driving Method	1/14 Scan, Constant Current
Rigging form	Hanging/Fixed with support bracket
