P1.25 indoor small pixel pitch led screen wall
It delivers an image which is super subtle and without getting tired after a longtime watching.
Super High Refresh Rate, High Frame Frequency, No Ghosting & Twisting or Smear.
Front Serviceable Module allows easy Maintenance, Saving Time & Spac.
16 Bit Grey Grade Processing, the color transition will be more natural.
16:9 New Generation Small Pitch Screen
Cabinet size is 16:9 golden ratio.Video pixel to LED pixel achieve full 2K/4K/8K displaying. No gap between unit is a revolution of visual enjoyment.
Parameters:
Pixel Structure |
SMD1010 |
LED Model |
1.25 |
Pixel Density(dots/m2) |
640000 |
Module Resolution(W×H) |
160×135 |
Module Size(mm) |
200(W)×168.75(H) |
Module Maximum Power Consumption(W) |
25 |
Module of Cabinet (W×H) |
3×2 |
Cabinet Resolution(W×H) |
480×270 |
Cabinet Size(mm) |
600(W)×337.5(H)×80(D) |
Cabinet Area(m2) |
0.2025 |
Cabinet Weight(kg) |
9.9 |
Cabinet Flatness(mm) |
≤0.2 |
Maintain Style |
Pre maintenance |
Cabinet Flatness(mm) |
≤0.1mm |
Cabinet Material |
die-cast aluminum |
singel pix brightness corretion |
have |
singel pix chroma corretion |
have |
white balance brightness(nits) |
200~600Adjustable |
Color Temperature(K) |
3200~9300Adjustable |
viewing angle (HorizontalVerticla) |
160/160 |
Light Pixel Centerline Spacing Difference |
<3% |
Brightness/Color Uniformity |
≥97% |
Contrast Ratio |
5000:1 |
Max Power consumption(W/m2) |
600 |
Avg Power Consumption(W/m2) |
250 |
Power supply requirement |
AC90~264V,frequency 47~63(Hz) |
