| Module | D6.25 |
| Pixel Pitch | 6.25mm |
| Pixel LED | SMD2727(Nationalstar) |
| Panel Resolution | 80x80 |
| Scan Mode | 1/5 |
| Panel Material | Aluminum |
| Panel Weight | 11kg/24.24 Ibs |
| Brightness | 1800 nits-5000 nits |
| IP Rating(Front/Rear) | IP65 |
| Refresh Rate | 2000Hz |
| Loading Ability | 1000 kg/sqm;2200Ibs/m2 |
| Panel Dimensions | 500*500*72mm/19.69*19.69*2.83 inch |
| Max Power Consumption | 200W/Panel |
| Color Processing | 16 bit |
| Viewing Angle(H/V) | 140°/110° |
| Operating Temperature | -20℃-50℃ |
| Input Voltage | AC 100-240V;50/60Hz |
