P3.91 indoor stage led display screen with 500*500mm cabinets.

1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.

2. Nice appearance and simple structures.

3. Jointed correctly, being installed & dismounted by one person without tool.

4. Humanized operating interface with breakdown indicator lights, easy to maintain.

5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

Big led display wall P3.91

Model	X500-1	X500-2	X500-3
Pixel Pitch	3.9mm	4.8mm	5.2mm
LED type	RGB 3in1 SMD2121	RGB 3in1 SMD2121	RGB 3in1 SMD3528
Pixel Density	65536	43402	36884
Resolution(WxH)	128*128dot	104*104 dot	192*96dot
Cabinet size	500x500x70mm
Weight	8kg	8kg	8kg
Waterproof rate	IP43
Brightness	1200nits	1200nits	2000nits
View Distance	4m	5m	5m
Viewing Angle (H/V)	140°/120°
Gray Scale	14bit
Color type	68 Billion
Max.Power Consumption	250W/PCS	120W/PCS	120W/PCS
Ave .Power Consumption	130W/PCS	60W/PCS	60W/PCS
Refresh rate	1960Hz
Gamma	-5.0~+5.0
Applied environment	INDOOR
Controller	Synchronous display with control PC by DVI
Support Input	Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI
Power input	AC 110-220V±10%
Environment	temperature -10°C~+50°C,humidity 10~90% RH
Operating Life	50,000hours
