Detailed Specifications
| Item | Parameter |
| Pixels(Pixel Pitch) | 2.976mm |
| Color Configuration | 1R1G1B 3in1 |
| LED Encapsulation | SMD1515 |
| Module Size | 250x250mm |
| Module Resolution | 84x84dots |
| Cabinet Size | 500x500mm |
| Cabinet Resolution | 168x168dots |
| Cabinet Weight | 7kg |
| Screen Size | Customized |
| Brightness | >1,500nits |
| Best Viewing Angle | H: 160°, V: 120° |
| Refresh Rate | >1,920HZ |
| Gray Level | 256levels of Each Color |
| Display Colors | 16.7millions |
| Lifespan | >100,000hrs |
| MTBF | >10,000hrs |
| Working Voltage | AC 110-220V ±10%, 50-60HZ |
| Max. Power Consumption | 560W/m² |
| Ave. Power Consumption | 220W/m² |
| Working Temperature | -40°C - +80°C |
| Working Humidity | 10% - 95%RH |
| Warranty | 2 Full Years |
| Certifications | CE, LVD, RoHS |
