P8 outdoor rental led display

Features
Specs
Application
Order

New Design Colorlight Outdoor P8 LED video wall, Waterproof SMD IP65 led display screen, Standard Size 960mmx960mm. Less Weight Magnesium Alloy LED Display Panel For Fixed led screen Installation

Product Features:
1: New Design
2: Less Weight, about 35KG/pc
3: Fast Lock Design, Easy Installtion
4: Magnesium Alloy Material
5: Standard Size Panel: 320*160mm
6: Standard Cabinet Size: 960*960mm
7: Unify the Standard LED Display Cabinet Screw Holes for all Kinds of standard led module.

P8 outdoor rental led display

Item	P8 Aluminum LED Display
Pixel Pitch（mm）	6.67mm	8mm
LED Type	3535	3535
Viewing angle:	H:140°,V：140°	H:140°,V：140°
Brightness（nits）	≥5000	≥6500
Drive Method	1/6	1/5
Color Depth（nits）	65536
Refresh Rate（Hz）	1920	1920
Module Size（mm）	320×160	320×160
Cabinet Size（mm）	640×960	640×960
Cabinet Material	Die casting aluminum
Cabinet weight（kg）	15.6	15.6
Voltage	110/240V
Average power（W / m²）	400	350
Max power（W / m²）	900	850
IP Grade	IP65/IP54.
Operating temperature/humidity	temperature：-20℃～ 50℃ humidity：10～90%RH
Storage temperature/humidity	temperature：-40℃～ 60℃ humidity：10～90%RH
Lifetime(h)	≥50000
Compliant Standard	CCC、CE
