| Item | LED Stadium Screen Display | ||
| Pixel Pitch(mm) | 10mm | 10mm | 16mm |
| Pixel density(dot/m2) | 10000 | 10000 | 3906 |
| LED Type | DIP346 | SMD3535 | DIP346 |
| Viewing angle: | H:120°,V:60° | H:120°,V:120° | H:120°,V:60° |
| Brightness(nits) | ≥6000 | ||
| Drive Method | 1/4. | 1/2. | Static |
| Color Depth(nits) | 16384 | ||
| Refresh Rate(Hz) | 1920 | 1920 | 3000 |
| Module Size(mm) | 160×160×28.5 | 160×160×18 | 256×128×28.5 |
| Cabinet Size(mm) | 1280×960×178.5 | 1280×960×168 | 1024×896×178.5 |
| Cabinet Material | Iron Sheet Metal | ||
| Cabinet weight(kg) | 68 | 68 | 50 |
| Voltage | 110/240V | ||
| Average.power(W / m2) | 250 | 250 | 220 |
| Max.power(W / m2) | 750 | 750 | 650 |
| IP Grade | IP65/IP54 | ||
| Operating temperature | temperature:-20℃~ 50℃ humidity:10~90%RH | ||
| Storage temperature | temperature:-40℃~ 60℃ humidity:10~90%RH | ||
| Lifetime(h) | ≥50000 | ||
